Tractor · 2015Unverified

Kubota STW37

Name: Kubota STW37
Brand: Kubota

Kubota STW37 — STW Series · 37 hp. Reference specifications; pending source verification.

The Kubota STW37 is a tractor with a rated power of 37 horsepower, which positions it at the lighter end of its class. Built in 2015, it is equipped with a 3-cylinder diesel liquid-cooled engine and a four-wheel drive system, paired with a hydrostatic transmission. The STW37 has an operating weight of 2436 to 2756 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Weight

2436 to 2756 pounds

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

37 hp

Recorded weight

1104 kg

Transmissions

hydrostatic

Production years

2015-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.8L 3-cyl dieselReference

Fuel tank29.5 LReference

Engine (gross)27.3 kWReference

Engine (net)25.9 kWReference

Kubota D1803Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke86 x 102 mmReference

Rated Power (net)25.9 kWReference

Rated Power (gross)27.3 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)19.0 kWReference

Pressure169.7 barReference

Pump flow29.9 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2670Reference

Engine RPM800@2717Reference

Engine RPM1000@2717Reference

Mid PTOindependentReference

Mid PTO Type2500Reference

Engine RPM2500@2734Reference

Dimensions

Wheelbase161 cmReference

Weight2436 to 2756 poundsReference

Front tire6.00-12Reference

Rear tire9.5-22Reference

Standard tires (ag)Front: 6.00-12. Rear: 9.5-22Reference

Lawn/turf front24x8.50-14Reference

Lawn/turf rear13.6-16Reference

Length294 cmReference

Width118 cmReference

Height (ROPS)234 cmReference

Height (cab)216 cmReference

ROPS Weight1104 kgReference

Cab Weight1250 kgReference

Ground clearance23 cmReference

Front tread102 cmReference

Rear tread94 to 106 cmReference

Kubota STW37 attachments

152 cm mid-mount mower deckReference

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Cab Charging amps60Reference

Battery volts12Reference

Attachment overview

152 cm mid-mount mower deckReference

Front-end loaderReference

60" Mower deck

Typemid-mount Kubota RCK-60Reference

Cutting width152 cmReference
