Tractor · 2015Unverified

Kubota STW40

Kubota STW40 — STW Series · 39 hp. Reference specifications; pending source verification.

The Kubota STW40 is a compact tractor, rated at 39 hp. It was manufactured in 2015. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine and a hydrostatic transmission, driving through four-wheel drive. Its listed weight ranges from 2436 to 2756 pounds, making it suitable for areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
39 hp
Weight
2436 to 2756 pounds

Catalogue coverage

Variants represented
2
Richest spec table
64 rows
Recorded power
39 hp
Recorded weight
1104 kg
Transmissions
hydrostatic
Production years
2015-2015
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.8L 3-cyl dieselReference
Fuel tank29.5 LReference
Engine (gross)28.7 kWReference
Engine (net)27.3 kWReference
Kubota D1803Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke86 x 102 mmReference
Rated Power (net)27.3 kWReference
Rated Power (gross)28.7 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference

Transmission

hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)20.4 kWReference
Pressure169.7 barReference
Pump flow29.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2670Reference
Engine RPM800@2717Reference
Engine RPM1000@2717Reference
Mid PTOindependentReference
Mid PTO Type2500Reference
Engine RPM2500@2734Reference

Dimensions

Wheelbase161 cmReference
Weight2436 to 2756 poundsReference
Front tire6.00-12Reference
Rear tire9.5-22Reference
Standard tires (ag)Front: 6.00-12. Rear: 9.5-22Reference
Lawn/turf front24x8.50-14Reference
Lawn/turf rear13.6-16Reference
Length294 cmReference
Width118 cmReference
Height (ROPS)234 cmReference
Height (cab)216 cmReference
ROPS Weight1104 kgReference
Cab Weight1250 kgReference
Ground clearance23 cmReference
Front tread102 cmReference
Rear tread94 to 106 cmReference

Kubota STW40 attachments

152 cm mid-mount mower deckReference
front-end loaderReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Cab Charging amps60Reference
Battery volts12Reference

Attachment overview

152 cm mid-mount mower deckReference
Front-end loaderReference

60" Mower deck

Typemid-mount Kubota RCK-60Reference
Cutting width152 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
