The Kubota T240 is a compact tractor, rated at 24 hp, making it a suitable option for smaller-scale operations. It was produced from 2000 to 2002, featuring a 3-cylinder electric liquid-cooled engine. This engine powers the tractor's four-wheel drive system, which is equipped with a hydrostatic transmission. The listed weight of the Kubota T240 ranges from 1984 to 2072 pounds, and it is designed for working on areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1984 to 2072 pounds
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
24 hp
Recorded weight
899 kg
Transmissions
12-speed gear
Production years
2000-2002
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Two-post folding ROPS.Reference
Variants
T240gearReference
T240F4WDReference
Engine
Kubota 1.5L 3-cyl diselReference
Fuel tank28.0 LReference
Engine17.7 kWReference
Kubota D1463Reference
diselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke82 x 92 mmReference
Power17.7 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
hydrostaticReference
Gear Weight899 kgReference
TypegearReference
Gears12 forward and 4 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Rear TypeJIS-1Reference
Rear PTO Type540 (1.375)Reference
Engine RPM525@2600Reference
Engine RPM760@2600Reference
Engine RPM1182@2600Reference
Engine RPM-518@2600Reference
Dimensions
Wheelbase145 cmReference
Weight1984 to 2072 poundsReference
Front tire6-14Reference
Rear tire9.5-22Reference
Standard tires (ag)Front: 6-14. Rear: 9.5-22Reference
