The Kubota X-24 is a compact tractor model, rated at 24 hp. It was produced from 1987 to 1992, and features a 4-cylinder diesel liquid-cooled engine. The engine drives four-wheel drive through a 9-speed gearbox, with a listed weight of 825 kg. The X-24 is suitable for jobs involving up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
825 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
24 hp
Recorded weight
825 kg
Transmissions
9-speed
Production years
1987-1992
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
Four-wheel driveReference
Open operator station. Half-cab available.Reference
Engine
Kubota 1.4L 4-cyl dieselReference
Fuel tank26.9 LReference
Engine17.7 kWReference
Kubota V1405Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement1.4 LReference
Bore/Stroke76 x 70 mmReference
Power17.7 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speedReference
12-speed creeperReference
Gears9 forward and 3 reverseReference
TypecreeperReference
Gears12 forward and 34 reverseReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM554@2600Reference
Engine RPM802@2600Reference
Engine RPM1182@2600Reference
Dimensions
Wheelbase145 cmReference
Weight825 kgReference
Front tire6-14Reference
Rear tire9.5R-22Reference
Standard tires (ag)Front: 6-14. Rear: 9.5R-22Reference
