Lawn Tractor · 2018Unverified

Kubota Z781

Name: Kubota Z781
Brand: Kubota

Kubota Z781 — Z700 Series · 30 hp. Reference specifications; pending source verification.

The Kubota Z781 is a 30 hp lawn tractor, positioned within the higher-powered machines of its class. Manufactured in 2018, the model features a 2-cylinder petrol air-cooled engine, transmitting power through a two-wheel drive system with hydrostatic transmission. The listed weight of the Kubota Z781 is 568 kg, and it is suitable for use on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

568 kg

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

30 hp

Recorded weight

568 kg

Transmissions

hydrostatic

Production years

2018-2018

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Zero-turn mowerReference

Original price was $10,699 in 2021Reference

Two-wheel driveReference

Power steeringReference

Drum brakesReference

Two-post folding ROPS.Reference

Engine

29.5HP Kawasaki 852cc 2-cyl gasolineReference

Fuel tank43.9 LReference

Kawasaki FX850V-EFIReference

gasolineReference

2-cylinderReference

air-cooled vertical-shaft V-TwinReference

Displacement52 ciReference

Bore/Stroke85 x 76 mmReference

Power (gross)22.0 kWReference

Fuel systemelectronic fuel injectionReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TransmissionParker HTG14Reference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Mid PTOindependentReference

Clutchelectro-magneticReference

Dimensions

Wheelbase129 cmReference

Weight568 kgReference

Front tire13x6.5-6Reference

Rear tire24x9.5-14Reference

Lawn/turf front13x6.5-6Reference

Lawn/turf rear24x9.5-14Reference

Length213 cmReference

Width128 cmReference

Height (ROPS)178 cmReference

Height (Folded ROPS)123 cmReference

Front tread95 cmReference

Rear tread102 cmReference

Kubota Z781 attachments

54" mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging amps15Reference

Battery CCA300Reference

Battery volts12Reference

54" Mower deck

Typemid-mount Kubota RCK54P-781ZReference

Type3-bladeReference

Cutting width137 cmReference

Overall width170 cmReference

Cut height2 to 13 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
