Lawn Tractor · 2018Unverified
Kubota Z781
Kubota Z781 — Z700 Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
568 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Zero-turn mowerReference
Original price was $10,699 in 2021Reference
Two-wheel driveReference
Power steeringReference
Drum brakesReference
Two-post folding ROPS.Reference
Engine
29.5HP Kawasaki 852cc 2-cyl gasolineReference
Fuel tank43.9 LReference
Kawasaki FX850V-EFIReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement52 ciReference
Bore/Stroke85 x 76 mmReference
Power (gross)22.0 kWReference
Fuel systemelectronic fuel injectionReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionParker HTG14Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
Clutchelectro-magneticReference
Dimensions
Wheelbase129 cmReference
Weight568 kgReference
Front tire13x6.5-6Reference
Rear tire24x9.5-14Reference
Lawn/turf front13x6.5-6Reference
Lawn/turf rear24x9.5-14Reference
Length213 cmReference
Width128 cmReference
Height (ROPS)178 cmReference
Height (Folded ROPS)123 cmReference
Front tread95 cmReference
Rear tread102 cmReference
Kubota Z781 attachments
54" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery CCA300Reference
Battery volts12Reference
54" Mower deck
Typemid-mount Kubota RCK54P-781ZReference
Type3-bladeReference
Cutting width137 cmReference
Overall width170 cmReference
Cut height2 to 13 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
