Lawn Tractor · 2001Unverified

Kubota ZD18

Name: Kubota ZD18
Brand: Kubota

Kubota ZD18 — ZD Series · 18 hp. Reference specifications; pending source verification.

The Kubota ZD18 is a lawn tractor model with an estimated power output of 18 horsepower, a typical rating for its class. It was produced from 2001 to 2006. The unit features a 3-cylinder diesel engine with liquid cooling, paired with a hydrostatic transmission and two-wheel drive. Its operating weight is listed as 611 kg, with a stated maximum operational area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

18 hp

Weight

611 kg

Catalogue coverage

Variants represented

Richest spec table

42 rows

Recorded power

18 hp

Recorded weight

611 kg

Transmissions

hydrostatic

Production years

2001-2006

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Zero-turn mowerReference

Two-wheel driveReference

Steeringdifferential powerReference

Two-post foldable ROPS.Reference

Engine

18HP Kubota 719cc 3-cyl dieselReference

Fuel tank29.9 LReference

Kubota D722Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement43.9 ciReference

Bore/Stroke67 x 68 mmReference

Power (gross)13.4 kWReference

Rated RPM3200Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Mid PTOindependentReference

Dimensions

Wheelbase124 cmReference

Weight611 kgReference

Front tire15x6.0-6Reference

Rear tire23x10.50-12Reference

Lawn/turf front15x6.0-6Reference

Lawn/turf rear23x10.50-12Reference

Length203 cmReference

Width134 cmReference

Height (steering wheel)114 cmReference

Height (ROPS)191 cmReference

Front tread97 cmReference

Rear tread107 cmReference

Kubota ZD18 attachments

54" mid-mount mower deckReference

Electrical

GroundnegativeReference

Battery CCA450Reference

Battery volts12Reference

54" Mower deck

Typemid-mount Kubota RCK54-18ZReference

Type3-bladeReference

Cutting width137 cmReference

Overall width168 cmReference

Cut height2 to 12 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
