Tractor · 1984Unverified
Lamborghini 1306
Lamborghini 1306 — Row-Crop tractor · 125 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
125 hp
Weight
10802 to 11243 pounds
Hover a source tag to verify
Overview
ManufacturerLamborghini (a part of SAME)Reference
Row-Crop tractorReference
Four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Cab available with air-conditioning.Reference
Engine
Lamborghini 5.5L 6-cyl dieselReference
Fuel tank240.0 LReference
Engine93.2 kWReference
Lamborghini 916.6 WTReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.5 LReference
Bore/Stroke103 x 110 mmReference
Power93.2 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2260Reference
Torque448.0 NmReference
Torque RPM1500Reference
Starter volts12Reference
Transmission
24-speedReference
16-speed creeperReference
Gears24 forward and 12 reverseReference
Clutchhydraulic cerametallic discReference
Four gears (1-4) in three ranges (S/N/F) with two-speed high-low shift.Reference
TypecreeperReference
Gears16 forward and 12 reverseReference
PTO & Hydraulics
Pump flow65.9 lpmReference
Rear TypeIII/IIReference
Controlposition and draft controlReference
Rear lift5399 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase275 cmReference
Weight10802 to 11243 poundsReference
Front tire14.9/13-30Reference
Rear tire18.4/15-38Reference
Ag front14.9/13-30Reference
Ag rear18.4/15-38Reference
Ag front16.9/14-30Reference
Ag rear20.8-38Reference
Length432 cmReference
Width216 cmReference
ROPS Weight4899 kgReference
Cab Weight5099 kgReference
Ground clearance50 cmReference
Front tread169 to 199 cmReference
Rear tread169 to 219 cmReference
Electrical
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps55Reference
Battery volts12Reference
Battery AH143Reference
Lamborghini 1306 Height
Hood183 cmReference
ROPS271 cmReference
Cab275 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
