Tractor · 1984Unverified
Lamborghini 1506
Lamborghini 1506 — Row-Crop tractor · 145 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
145 hp
Weight
12345 to 12786 pounds
Hover a source tag to verify
Overview
ManufacturerLamborghini (a part of SAME)Reference
Row-Crop tractorReference
Four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Cab available with air-conditioning.Reference
Engine
Lamborghini 6.8L 6-cyl dieselReference
Fuel tank230.1 LReference
Engine108.1 kWReference
Lamborghini 1106/14TReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke110 x 120 mmReference
Power108.1 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2180Reference
Torque537.1 NmReference
Torque RPM1260Reference
Starter volts12Reference
Transmission
24-speedReference
16-speed creeperReference
Gears24 forward and 12 reverseReference
Clutchhydraulic cerametallic discReference
Four gears (1-4) in three ranges (S/N/F) with two-speed high-low shift.Reference
TypecreeperReference
Gears16 forward and 12 reverseReference
PTO & Hydraulics
Pump flow63.2 lpmReference
Rear TypeIII/IIReference
Controlposition and draft controlReference
Rear lift5399 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase285 cmReference
Weight12345 to 12786 poundsReference
Front tire16.9/14-30Reference
Rear tire20.8-38Reference
Ag front16.9/14-30Reference
Ag rear20.8-38Reference
Ag front14.9/13-30Reference
Ag rear18.4/15-38Reference
Length451 cmReference
Width222 cmReference
ROPS Weight5599 kgReference
Cab Weight5799 kgReference
Ground clearance53 cmReference
Front tread180 to 199 cmReference
Rear tread169 to 219 cmReference
Electrical
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps55Reference
Battery volts12Reference
Battery AH143Reference
Lamborghini 1506 Height
Hood186 cmReference
ROPS274 cmReference
Cab280 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
