Tractor · 1982Unverified
Lamborghini 583
Lamborghini 583 — Utility tractor · 53 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Weight
4343 to 4850 pounds
Hover a source tag to verify
Overview
ManufacturerLamborghiniReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Variants
583utility tractorReference
C583crawlerReference
Engine
SAME 2.8L 3-cyl dieselReference
Fuel tank54.1 LReference
Engine (net)39.5 kWReference
SAMEReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 120 mmReference
Power (net)39.5 kWReference
Air cleaneroil bathReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and 3 reverseReference
Clutch279.4mm dry discReference
PTO & Hydraulics
Pump flow21.6 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2500 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type1000Reference
Dimensions
Wheelbase200 cmReference
Weight4343 to 4850 poundsReference
Front tire6.00-16Reference
2WD Rear tire13.6/12-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6/12-28Reference
4WD Standard tires (ag)Front: 9.5/9-20. Rear: 13.6/12-28Reference
2WD Optional tires (ag)Front: 6.50-16. Rear: 14.9/13-28Reference
2WD Optional tires (ag)Front: 6.00-19. Rear: 12.4/11-32Reference
4WD Optional tires (ag)Front: 8.3/8-24. Rear: 14.9/13-28Reference
4WD Optional tires (ag)Front: 8.3/8-24. Rear: 12.4/11-32Reference
Length329 cmReference
Height (ROPS)219 cmReference
Height (exhaust)214 cmReference
2WD Weight1969 kgReference
4WD Weight2199 kgReference
2WD Ground clearance46 cmReference
4WD Ground clearance26 cmReference
2WD Front tread120 to 170 cmReference
4WD Front tread136 to 184 cmReference
Rear tread125 to 185 cmReference
Electrical
Charging systemalternatorReference
Charging amps33Reference
Battery volts12Reference
Battery AH88Reference
Speeds
With 13.6/12-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
