Tractor · 1982Unverified
Lamborghini 684
Lamborghini 684 — Utility tractor · 72 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
72 hp
Weight
5842 to 6393 pounds
Hover a source tag to verify
Overview
ManufacturerLamborghiniReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Variants
684utility tractorReference
C684crawlerReference
684ForchardReference
Engine
SAME 3.6L 4-cyl dieselReference
Fuel tank65.1 LReference
Engine (gross)53.7 kWReference
Engine (net)52.2 kWReference
SAMEReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.6 LReference
Bore/Stroke105 x 120 mmReference
Power (net)52.2 kWReference
Power (gross)53.7 kWReference
Rated RPM2150Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronizedReference
16-speed creeperReference
TypesynchronizedReference
Gears12 forward and 3 reverseReference
Clutch279.4mm dry discReference
TypecreeperReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Pump flow29.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift3000 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase226 cmReference
4WD Wheelbase228 cmReference
Weight5842 to 6393 poundsReference
Front tire7.50-16Reference
2WD Rear tire16.9/14-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9/14-30Reference
4WD Standard tires (ag)Front: 11.2/10-24. Rear: 16.9/14-30Reference
2WD Optional tires (ag)Front: 6.50-16. Rear: 14.9/13-30Reference
2WD Optional tires (ag)Front: 6.50-20. Rear: 13.6/12-36Reference
4WD Optional tires (ag)Front: 9.5/9-24. Rear: 14.9/13/30Reference
4WD Optional tires (ag)Front: 12.4/11-24. Rear: 13.6/12-36Reference
Length354 cmReference
Height (hood)160 cmReference
Height (cab)237 cmReference
2WD Weight2649 kgReference
4WD Weight2899 kgReference
2WD Ground clearance50 cmReference
4WD Ground clearance37 cmReference
2WD Front tread145 to 195 cmReference
4WD Front tread132 to 182 cmReference
Rear tread139 to 199 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Battery AH110Reference
Speeds
With 16.9-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
