Tractor · 1980Unverified
Lamborghini C784
Lamborghini C784 — Agricultural Crawler tractor · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
4320 kg
Hover a source tag to verify
Overview
ManufacturerLamborghiniReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Variants
784utility tractorReference
C784crawlerReference
Engine
SAME 4.2L 4-cyl dieselReference
Fuel tank71.9 LReference
Engine (gross)63.4 kWReference
Engine (net)58.2 kWReference
SAMEReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power (net)58.2 kWReference
Power (gross)63.4 kWReference
Air cleaneroil bathReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
8-speed shuttleReference
16-speed creeperReference
TypegearReference
Gears8 forward and 4 reverseReference
Clutch304.8mm dry discReference
TypeshuttleReference
Gears8 forward and reverseReference
TypecreeperReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear lift3000 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase165 cmReference
Weight4320 kgReference
15.75-inch tracksReference
Length335 cmReference
Width180 cmReference
Height (hood)131 cmReference
Height (exhaust)223 cmReference
Gauge139 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Battery AH90Reference
Lamborghini C784 Tracks
Width40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
