Tractor · 1973Unverified
Lamborghini R 503
Lamborghini R 503 — Utility tractor · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
4188 to 4564 pounds
Hover a source tag to verify
Overview
ManufacturerLamborghiniReference
Utility tractorReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
503DT4WDReference
Engine
Lamborghini 2.8L 3-cyl dieselReference
Engine35.0 kWReference
LamborghiniReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 120 mmReference
Power35.0 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear lift3000 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase193 cmReference
Weight4188 to 4564 poundsReference
Front tire6.00-16Reference
2WD Rear tire13.6/12-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6/12-28Reference
4WD Standard tires (ag)Front: 9.5-20. Rear: 13.6/12-28Reference
2WD Optional tires (ag)Front: 6.00-16. Rear: 12.4/11-28Reference
2WD Optional tires (ag)Front: 6.00-19. Rear: 12.4/11-32Reference
2WD Optional tires (ag)Front: 6.50-16. Rear: 14.9/13-28Reference
4WD Optional tires (ag)Front: 8.00-20. Rear: 12.4/11-28Reference
4WD Optional tires (ag)Front: 8.3/8-24. Rear: 12.4/11-32Reference
4WD Optional tires (ag)Front: 9.5/8-24. Rear: 12.4/11-32Reference
4WD Optional tires (ag)Front: 8.3/8-24. Rear: 14.9/13-28Reference
4WD Optional tires (ag)Front: 9.5/9-24. Rear: 14.9/13-28Reference
Length331 cmReference
Height (steering wheel)159 cmReference
2WD Weight1899 kgReference
4WD Weight2070 kgReference
Ground clearance31 cmReference
2WD Front tread120 to 191 cmReference
4WD Front tread135 cmReference
Rear tread135 to 185 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
