Tractor · 2014Unverified
Landini 4-105
Landini 4-105 — 4 Series · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
7025 to 7775 pounds
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Utility tractorReference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Deutz 3.6L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine75.3 kWReference
Deutz C4DT74Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke98 x 120 mmReference
EmissionsInterim Tier IVReference
Emission controlcooled exhaust gas recirculation with diesel oxidation catalyst (DOC) (EGR)Reference
Power75.3 kWReference
Maximum Power79.8 kWReference
Fuel systemcommon railReference
Rated RPM2200Reference
Torque420.4 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed partially synchronizedReference
12-speed power shuttleReference
24-speed two-speed power shiftReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Clutch304.8mm dry discReference
Four synchronized gears in three ranges with mechanical shuttle. Also available with creeper range, providing 16 speeds.Reference
Typepower shuttleReference
Clutchhydraulic wet discReference
Four synchronized gears in three ranges with power shuttleReference
Typetwo-speed power shiftReference
Gears24 forward and reverseReference
Power Four adds a two-speed high/low power shift to the base transmission. Available with either synchronized shuttle or power shuttle.Reference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
Typeopen centerReference
Valves2 or 3Reference
Pump flow56.8 lpmReference
Steering flow32.2 lpmReference
Rear TypeIIReference
Rear lift2699 kgReference
Rear lift3900 kgReference
Rear Armstelescopic ends and stabilizersReference
Front HitchIIReference
Front lift1749 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase223 cmReference
Weight7025 to 7775 poundsReference
Length432 cmReference
Width175 cmReference
Height (ROPS)281 cmReference
Height (cab)246 cmReference
ROPS Weight3186 kgReference
Cab Weight3526 kgReference
Flange rear axleReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
