Tractor · 2010Unverified
Landini 5-115H
Landini 5-115H — 5H Series · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
3642 kg
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Two-post ROPS. Cab available with air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank102.2 LReference
Engine82.0 kWReference
Perkins 1104D-44TAReference
turbocharged aftercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIIReference
Power82.0 kWReference
Fuel systemdirect injectionReference
Transmission
36-speed partial power shift with hydraulic shuttleReference
24-speed partial power shift with shuttleReference
48-speed partial power shift with hydraulic shuttleReference
TransmissionTOP T-TRONICReference
Typepartial power shift with hydraulic shuttleReference
Gears36 forward and 12 reverseReference
The T-Tronic adds a high-medium-low power shift to the basic transmission with hydraulic shuttle.Reference
TransmissionSPEED FOUR OverdriveReference
Typepartial power shift with shuttleReference
Gears24 forward and 12 reverseReference
Overdrive on the basic transmission.Reference
TransmissionTOP T-TRONIC CreeperReference
Gears48 forward and 16 reverseReference
T-Tronic plus basic transmission with creeper increases available speeds.Reference
PTO & Hydraulics
Rear TypeIIReference
Front HitchIIReference
Front lift1796 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000 (1.375)Reference
Front PTOindependentReference
Clutchelectro-hydraulicReference
Front PTO Type1000Reference
Dimensions
2WD Wheelbase236 cmReference
4WD Wheelbase233 cmReference
Weight3642 kgReference
Front tire340/85R24Reference
Rear tire420/85R34Reference
Standard tires (ag)Front: 340/85R24. Rear: 420/85R34Reference
Length416 cmReference
Width208 cmReference
Height (ROPS)256 cmReference
Height (cab)256 cmReference
Ground clearance46 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
