Tractor · 1988Unverified
Landini 5560F
Landini 5560F — Orchard/Vineyard tractor · 52 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
4630 to 4916 pounds
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post mid-mount ROPS.Reference
Variants
5560ForchardReference
5560VvineyardReference
Engine
Perkins 2.5L 3-cyl dieselReference
Engine39.0 kWReference
Perkins 3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power39.0 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2250Reference
Torque170.0 NmReference
Torque RPM1350Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed syncromeshReference
24-speed creeperReference
TypesyncromeshReference
Gears12 forward and 4 reverseReference
Clutch279.4mm mechanical dry discReference
TypecreeperReference
Gears24 forward and 12 reverseReference
Capacities
Fuel46.0 LReference
PTO & Hydraulics
Hydraulic system32.9 LReference
Capacity32.9 LReference
Valves2Reference
Pump flow38.6 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750 (1.375)Reference
Engine RPM540@1944Reference
Engine RPM750@1934Reference
Dimensions
2WD Wheelbase195 cmReference
4WD Wheelbase189 cmReference
Weight4630 to 4916 poundsReference
Front tire9.00-10Reference
2WD Rear tire14.9R20Reference
2WD Standard tires (ag)Front: 9.00-10. Rear: 14.9R20Reference
4WD Standard tires (ag)Front: 9.00/7.5-16. Rear: 14.9R20Reference
2WD Optional tires (ag)Front: 9.00-10. Rear: 175/70R20Reference
2WD Optional tires (ag)Front: 5.00-15. Rear: 320-70-24Reference
4WD Optional tires (ag)Front: 6.50-16. Rear: 375/75R20Reference
4WD Optional tires (ag)Front: 7.50-16. Rear: 320/70R24Reference
Length332 cmReference
Width137 cmReference
Height (hood)123 cmReference
Height (ROPS)231 cmReference
2WD Weight2100 kgReference
4WD Weight2229 kgReference
Clearance (drawbar)36 cmReference
2WD Front tread110 to 135 cmReference
4WD Front tread108 to 149 cmReference
Rear tread99 to 129 cmReference
Electrical
GroundnegativeReference
Charging systemLucas A115Reference
Charging amps45Reference
Battery volts12Reference
Speeds
With 14.9R20 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
