Tractor · 2014Unverified
Landini 6-145L
Landini 6-145L — 6L Series · 129 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
129 hp
Weight
5987 kg
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Row-Crop tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with air-conditioning.Reference
Variants
X6.460similar McCormick Intl modelReference
Engine
FPT 4.5L 4-cyl dieselReference
Fuel tank269.9 LReference
Exhaust fluid (DEF)37.9 LReference
Engine (gross)96.0 kWReference
Engine (max)105.0 kWReference
FPTReference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
EmissionsStage IVReference
Rated Power (gross)96.0 kWReference
Maximum Power (gross)105.0 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed mechanical shuttleReference
54-speed three-speed power shiftReference
TransmissionSpeed-SixReference
Typemechanical shuttleReference
Gears18 forward and reverseReference
Clutchmechanical dry discReference
Six speeds in three ranges with manual shuttle shift. Also available with creeper range that doubles speeds to 36/36.Reference
TransmissionTop-TronicReference
Typethree-speed power shiftReference
Gears54 forward and 18 reverseReference
Clutchelectro-hydraulic wet discReference
Six speeds in three ranges with three-speed power shift and power shuttle. Also available with creeper range that doubles speeds to 108/36.Reference
PTO & Hydraulics
Pump flow87.1 lpmReference
SCV flow87.1 lpmReference
Total flow124.9 lpmReference
Steering flow37.9 lpmReference
Rear TypeIII/IIReference
Front HitchIIReference
Front lift3499 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase271 cmReference
Weight5987 kgReference
Front tire480/65R28Reference
Rear tire650/65R38Reference
Standard tires (ag)Front: 480/65R28. Rear: 650/65R38Reference
Length525 cmReference
Height (cab)279 cmReference
Flange rear axleReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
