Tractor · 2014Unverified
Landini 6-175L
Landini 6-175L — 6L Series · 168 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
168 hp
Weight
6137 kg
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Row-Crop tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with air-conditioning.Reference
Variants
X6.480similar McCormick Intl modelReference
Engine
FPT 4.5L 4-cyl dieselReference
Fuel tank269.9 LReference
Exhaust fluid (DEF)37.9 LReference
Engine (gross)125.0 kWReference
Engine (max)129.0 kWReference
FPTReference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
EmissionsStage IVReference
Rated Power (gross)125.0 kWReference
Maximum Power (gross)129.0 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed mechanical shuttleReference
54-speed three-speed power shiftReference
TransmissionSpeed-SixReference
Typemechanical shuttleReference
Gears18 forward and reverseReference
Clutchmechanical dry discReference
Six speeds in three ranges with manual shuttle shift. Also available with creeper range that doubles speeds to 36/36.Reference
TransmissionTop-TronicReference
Typethree-speed power shiftReference
Gears54 forward and 18 reverseReference
Clutchelectro-hydraulic wet discReference
Six speeds in three ranges with three-speed power shift and power shuttle. Also available with creeper range that doubles speeds to 108/36.Reference
PTO & Hydraulics
Pump flow87.1 lpmReference
SCV flow87.1 lpmReference
Total flow124.9 lpmReference
Steering flow37.9 lpmReference
Rear TypeIII/IIReference
Front HitchIIReference
Front lift3499 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase271 cmReference
Weight6137 kgReference
Front tire480/65R28Reference
Rear tire650/65R38Reference
Standard tires (ag)Front: 480/65R28. Rear: 650/65R38Reference
Length525 cmReference
Height (cab)279 cmReference
Flange rear axleReference
Bar rear axleReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
