The Landini 6560F is a tractor rated at 65 hp, positioning it within the mid-range of its class in terms of power output. Manufactured from 1988 to 1995, the 6560F features a 4-cylinder diesel liquid-cooled engine and a four-wheel drive system with a 12-speed gearbox. This tractor is designed for use in fields of up to 200 acres. Specifications are available for both UK and US markets.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
65 hp
Transmissions
12-speed syncromesh
Production years
1988-1995
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Two-post mid-mount ROPS.Reference
Variants
6560ForchardReference
6560Lwide orchardReference
Engine
Perkins 3.9L 4-cyl dieselReference
Engine48.5 kWReference
Perkins 4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power48.5 kWReference
Air cleanerdryReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed syncromeshReference
24-speed creeperReference
TypesyncromeshReference
Gears12 forward and 4 reverseReference
Clutch279.4mm mechanical dry discReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear lift2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750 (1.375)Reference
Electrical
GroundnegativeReference
Charging systemLucas A115Reference
Charging amps45Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
