Tractor · 1988Unverified
Landini 7870
Landini 7870 — 70 Series · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Weight
6880 to 7360 pounds
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Utility tractorReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard.Reference
Variants
7860ROPSReference
7870CabinReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank85.9 LReference
Engine52.9 kWReference
Perkins A4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power52.9 kWReference
Rated RPM2200Reference
Torque269.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
PTO & Hydraulics
Pump flow35.6 lpmReference
Rear lift2600 kgReference
Rear PTO Type540/750Reference
Dimensions
Wheelbase226 cmReference
Weight6880 to 7360 poundsReference
Front tire7.50-20Reference
2WD Rear tire16.9R30Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 16.9R30Reference
4WD Standard tires (ag)Front: 13.6R24. Rear: 16.9R34Reference
Length370 cmReference
2WD Weight3120 kgReference
4WD Weight3338 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
