Tractor · 1987Unverified
Landini 8880
Landini 8880 — 80 Series · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
7606 to 8422 pounds
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockhydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with available air-conditioning.Reference
Engine
Perkins 4.1L 4-cyl dieselReference
Fuel tank102.2 LReference
Engine59.7 kWReference
Perkins A4.248Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power59.7 kWReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM2200Reference
Torque282.0 NmReference
Torque RPM1400Reference
Transmission
12-speed synchromeshReference
12-speed shuttleReference
24-speed synchromeshReference
24-speed creeperReference
TypesynchromeshReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
Four gears in three ranges.Reference
TypeshuttleReference
Gears12 forward and reverseReference
Four gears in three ranges with shuttle.Reference
Gears24 forward and 12 reverseReference
The base transmission can be equipped with either an underdrive or overdrive range. The underdrive option reduces base speeds by 22%. The overdrive option increases base speeds by 29%.Reference
TypecreeperReference
PTO & Hydraulics
Total flow42.4 lpmReference
Rear TypeIIReference
Controlposition control and top-link draft sensingReference
Rear lift2600 kgReference
Rear lift3700 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type540/750Reference
Engine RPM540@1944Reference
Engine RPM1000@1917Reference
Engine RPM750@1934Reference
Dimensions
2WD Wheelbase244 cmReference
4WD Wheelbase241 cmReference
Weight7606 to 8422 poundsReference
Front tire7.50-20Reference
Rear tire16.9R34Reference
Ag front7.50-20Reference
Ag rear16.9R34Reference
Ag front13.6R24Reference
Length387 cmReference
Width175 cmReference
Height (cab)262 cmReference
2WD Weight3450 kgReference
4WD Weight3820 kgReference
4WD Clearance (front axle)43 cmReference
Electrical
Charging systemalternatorReference
Speeds
With 16.9/14-34 rear tires. Reverse speeds are 1% faster than forward.Reference
With 16.9/14-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
