Tractor · 1995Unverified
Landini Advantage 75V
Landini Advantage 75V — Advantage Series · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
6063 to 6173 pounds
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount foldable ROPS. Cab optional.Reference
Variants
75GElow-profileReference
75ForchardReference
75Lwide orchardReference
75GTutilityReference
75VvineyardReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank54.1 LReference
Engine55.2 kWReference
Perkins 4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power55.2 kWReference
Air cleanerdryReference
Compression16:1Reference
Rated RPM2200Reference
Torque289.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed creeper with mechanical shuttleReference
12-speed mechanical shuttleReference
Typecreeper with mechanical shuttleReference
Gears24 forward and 12 reverseReference
Clutch279.4mm mechanial dry discReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear lift2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750 (1.375)Reference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase210 cmReference
4WD Wheelbase212 cmReference
Weight6063 to 6173 poundsReference
Front tire6.50-16Reference
2WD Rear tire13.6/12-24Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 13.6/12-24Reference
4WD Standard tires (ag)Front: 260/70R16. Rear: 13.6/24-24Reference
Length362 cmReference
Width122 cmReference
Height (steering wheel)130 cmReference
Height (cab)225 cmReference
2WD Weight2750 kgReference
4WD Weight2800 kgReference
Clearance (drawbar)40 cmReference
2WD Front tread100 to 138 cmReference
4WD Front tread115 to 142 cmReference
Rear tread122 to 131 cmReference
Electrical
GroundnegativeReference
Charging systemLucas A115Reference
Charging amps45Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
