Tractor · 2001Unverified
Landini Atlantis 100
Landini Atlantis 100 — Atlantis Series · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
3349 kg
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
Atlantis 100economyReference
Ghibli 100deluxeReference
Engine
Perkins 4.0L 4-cyl dieselReference
Fuel tank95.0 LReference
Engine69.4 kWReference
Perkins 1004-40TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
EmissionsStage IReference
Power69.4 kWReference
Rated RPM2200Reference
Torque387.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed shuttleReference
24-speed shuttle with creeperReference
24-speed shuttle with overdriveReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutch304.8mm dry discReference
Typeshuttle with creeperReference
Gears24 forward and 12 reverseReference
Typeshuttle with overdriveReference
PTO & Hydraulics
PTO (claimed)64.1 kWReference
Pressure180.0 barReference
Valves2Reference
Pump flow53.7 lpmReference
Total flow78.0 lpmReference
Steering flow23.8 lpmReference
Rear TypeIIReference
Rear lift2600 kgReference
Rear lift4350 kgReference
Rear PTOindependentReference
Clutchmechanical dry discReference
Rear PTO Type540/750 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase241 cmReference
Weight3349 kgReference
Front tire9.00-16Reference
2WD Rear tire480/70R34Reference
2WD Standard tires (ag)Front: 9.00-16. Rear: 480/70R34Reference
4WD Standard tires (ag)Front: 380/70R24. Rear: 480/70R34Reference
Length418 cmReference
Width192 cmReference
Height (steering wheel)171 cmReference
Height (ROPS)260 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
