Tractor · 2006Unverified
Landini Evolution 6865
Landini Evolution 6865 — 65 Evolution Series · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
2762 kg
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechnical rearReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Engine50.2 kWReference
Perkins 1104C-44Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke102 x 127 mmReference
EmissionsTier IIReference
Power50.2 kWReference
Compression19.3:1Reference
Rated RPM2200Reference
Torque272.6 NmReference
Torque RPM1400Reference
Transmission
12-speed mechanical shuttleReference
24-speed creeperReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
TypecreeperReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)46.5 kWReference
Hydraulic system45.8 LReference
Capacity45.8 LReference
Pressure179.3 barReference
Valves2Reference
Pump flow52.2 lpmReference
Total flow76.5 lpmReference
Rear TypeIIReference
Rear lift2594 kgReference
Rear lift3692 kgReference
Rear PTO Type540Reference
Capacities
Fuel87.1 LReference
Dimensions
Wheelbase224 cmReference
Weight2762 kgReference
Front tire7.50-16Reference
Rear tire16.9-30Reference
Ag front7.50-16Reference
Ag front11.2-24 (4WD)Reference
Ag rear16.9-30Reference
Length342 cmReference
Width182 cmReference
Height254 cmReference
Ground clearance39 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
