Tractor · 2006Unverified

Landini Evolution 8865

Name: Landini Evolution 8865
Brand: Landini

Landini Evolution 8865 — 65 Evolution Series · 74 hp. Reference specifications; pending source verification.

The Landini Evolution 8865 is a tractor equipped with a 4-cylinder diesel liquid-cooled engine, producing a rated output of 74 hp. It was manufactured from 2006 to 2010. The tractor features a hydrostatic transmission and four-wheel drive, with a listed weight of 3140 kg. It is designed to handle tasks on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

74 hp

Weight

3140 kg

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

74 hp

Recorded weight

3140 kg

Transmissions

12-speed mechanical shuttle

Production years

2006-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLandiniReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockmechnical rearReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Four-post ROPS.Reference

Engine

Perkins 4.4L 4-cyl dieselReference

Engine60.0 kWReference

Perkins 1104C-44Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke102 x 127 mmReference

EmissionsTier IIReference

Power60.0 kWReference

Compression19.3:1Reference

Rated RPM2200Reference

Torque291.5 NmReference

Torque RPM1400Reference

Transmission

12-speed mechanical shuttleReference

24-speed creeperReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

TypecreeperReference

Gears24 forward and reverseReference

PTO & Hydraulics

PTO (claimed)55.5 kWReference

Hydraulic system51.1 LReference

Capacity51.1 LReference

Pressure179.3 barReference

Valves2Reference

Pump flow52.2 lpmReference

Total flow76.5 lpmReference

Rear TypeIIReference

Rear lift2594 kgReference

Rear lift3692 kgReference

Rear PTO Type540Reference

Capacities

Fuel87.1 LReference

Dimensions

Wheelbase233 cmReference

Weight3140 kgReference

Front tire9.00-16Reference

Rear tire18.4-30Reference

Ag front9.00-16Reference

Ag front12.4-24 (4WD)Reference

Ag rear18.4-30Reference

Length381 cmReference

Width186 cmReference

Height259 cmReference

Ground clearance43 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
