Tractor · 1999Unverified
Landini Globus 55
Landini Globus 55 — Globus Series · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
5390 to 5650 pounds
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Utility tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockmechanicalReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulic optionalReference
Cab with heater standard. Optional air-conditioning and digital dashboard. Optional ROPS canopy.Reference
Variants
Globus 55 GTlow-profileReference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank53.0 LReference
Fuel tank34.1 LReference
Engine41.0 kWReference
Perkins 903-27Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power41.0 kWReference
Rated RPM2300Reference
Starter volts12Reference
Transmission
15-speed synchronized shuttleReference
30-speed synchronized shuttleReference
30-speed partial power shiftReference
60-speed partial power shiftReference
Typesynchronized shuttleReference
Gears15 forward and reverseReference
Clutch279mm cerametallic mechanical dry discReference
Base transmission. Synchronized with synchronized shuttle reverser. On 2WD tractors the transmission has 12/12 gears.Reference
Gears30 forward and reverseReference
Synchronized shuttle with synchronized reverser and creeper range. On 2WD tractors the transmission has 24/24 gears.Reference
Typepartial power shiftReference
Synchronized shuttle with electro-hydraulic two-speed power shift. On 2WD tractors the transmission has 24/24 gears.Reference
Gears60 forward and reverseReference
Synchronized shuttles with electro-hydraulic two-speed power shift and creeper range. On 2WD tractors the transmission has 48/48 gears.Reference
PTO & Hydraulics
PTO (claimed)35.0 kWReference
Pressure179.3 barReference
Valves2 or 3Reference
SCV flow39.4 lpmReference
Total flow67.4 lpmReference
Rear Type2Reference
Controlposition and draft controlReference
Rear lift2086 kgReference
Rear lift3402 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000/groundReference
Rear PTO Type540/750/groundReference
Dimensions
2WD Wheelbase207 cmReference
4WD Wheelbase200 cmReference
GT Wheelbase199 cmReference
Weight5390 to 5650 poundsReference
Front tire7.50-16Reference
Rear tire14.9R28 (2WD)Reference
Standard tires (ag)Front: 7.50-16. Rear: 14.9R28 (2WD)Reference
Standard tires (ag)Front: 320/70R20. Rear: 420/70R28 (4WD)Reference
Standard tires (ag)Front: 300/70R20. Rear: 480/70R24 (GT)Reference
Optional tires (ag)Front: 7.50-16. Rear: 14.9-28 (2WD)Reference
Optional tires (ag)Front: 12.4R20. Rear: 14.9R30 (4WD)Reference
Optional tires (ag)Front: 11.2R20. Rear: 14.9R28 (4WD)Reference
Optional tires (ag)Front: 360/70R20. Rear: 420/70R30 (4WD)Reference
Optional tires (ag)Front: 340/75R20. Rear: 540/65R28 (4WD)Reference
Optional tires (ag)Front: 320/70R20. Rear: 14.9R28 (GT)Reference
Optional tires (ag)Front: 320/70R20. Rear: 480/65R28 (GT)Reference
Optional tires (ag)Front: 275/80R20. Rear: 380/70R28 (GT)Reference
Optional tires (ag)Front: 300/70R20. Rear: 480/70R24 (GT)Reference
Lawn/turf front29x12.5-15 (GT)Reference
Lawn/turf rear21.5L-16.1 (GT)Reference
Industrial front10.5-18 (4WD)Reference
Industrial rear17.5L-24 (4WD)Reference
Length394 cmReference
Width175 cmReference
GT Width172 cmReference
Height (cab)234 cmReference
GT Height (cab)229 cmReference
Ground clearance44 cmReference
GT Ground clearance33 cmReference
Front tread143 to 170 cmReference
Rear tread158 to 185 cmReference
2WD2444 kgReference
4WD2562 kgReference
GT2453 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
