Tractor · 1996Unverified
Landini Globus 70
Landini Globus 70 — Globus Series · 66 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
66 hp
Weight
5181 to 5952 pounds
Hover a source tag to verify
Overview
ManufacturerLandiniReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanicalReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Perkins 3.0L 4-cyl dieselReference
Engine49.2 kWReference
PerkinsReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke97 x 100 mmReference
Power49.2 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
24-speedReference
Gears12 forward and reverseReference
Gears24 forward and reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Total flow40.1 lpmReference
Rear lift2100 kgReference
Rear lift3400 kgReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase207 cmReference
4WD Wheelbase200 cmReference
Weight5181 to 5952 poundsReference
Front tire7.50x16Reference
2WD Rear tire14.9R28Reference
2WD Standard tires (ag)Front: 7.50x16. Rear: 14.9R28Reference
4WD Standard tires (ag)Front: 12.4R20. Rear: 14.9R28Reference
Length364 cmReference
Height (cab)245 cmReference
2WD Weight2350 kgReference
4WD Weight2699 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
