Tractor · 2005Unverified
Landini Landpower 135
Landini Landpower 135 — Model year 2005-20072007-2018 · 132 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
132 hp
Weight
5800 kg
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Perkins 6.0L 6-cyl dieselReference
Fuel tank260.0 LReference
Engine (gross)98.6 kWReference
Engine (net)92.7 kWReference
Standard tires (ag)Front: 420/70R28. Rear: 520/70R38Reference
Perkins 1106-E60TAReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
EmissionsStage IIReference
Power (net)92.7 kWReference
Power (gross)98.6 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed mechanical shuttleReference
72-speedReference
54-speed three-speed power shiftReference
TransmissionSpeed-SixReference
Typemechanical shuttleReference
Gears18 forward and reverseReference
Clutchmechanical dry discReference
Six speeds in three ranges with manual shuttle shift. Also available with creeper range that doubles speeds to 36/36.Reference
TransmissionPower-SixReference
Gears72 forward and reverseReference
TransmissionTop-TronicReference
Typethree-speed power shiftReference
Gears54 forward and 18 reverseReference
Clutchelectro-hydraulic wet discReference
Six speeds in three ranges with three-speed power shift and power shuttle. Also available with creeper range that doubles speeds to 108/36.Reference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase279 cmReference
Weight5800 kgReference
Front tire420/70R28Reference
Rear tire520/70R38Reference
Length515 cmReference
Height (cab)279 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
