Landini Landpower II 125
Landini Landpower II 125 — Landpower II Series · 115 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Weight
5987 kg
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Row-Crop tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with air-conditioning.Reference
Engine
FPT 6.7L 6-cyl dieselReference
Fuel tank260.0 LReference
Engine (gross)86.0 kWReference
Standard tires (ag)Front: 14.9R28. Rear: 18.4R38Reference
FPTReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
EmissionsStage IIIReference
Power (gross)86.0 kWReference
Rated RPM2200Reference
Torque515.3 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed mechanical shuttleReference
54-speed three-speed power shiftReference
TransmissionSpeed-SixReference
Typemechanical shuttleReference
Gears18 forward and reverseReference
Clutchmechanical dry discReference
Six speeds in three ranges with manual shuttle shift. Also available with creeper range that doubles speeds to 36/36.Reference
TransmissionTop-TronicReference
Typethree-speed power shiftReference
Gears54 forward and 18 reverseReference
Clutchelectro-hydraulic wet discReference
Six speeds in three ranges with three-speed power shift and power shuttle. Also available with creeper range that doubles speeds to 108/36.Reference
PTO & Hydraulics
Typeopen centerReference
Typeclosed-center load sensingReference
Pump flow104.8 lpmReference
Pump flow148.0 lpmReference
Rear TypeIIReference
Front HitchIIReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase279 cmReference
Weight5987 kgReference
Front tire14.9R28Reference
Rear tire18.4R38Reference
Length534 cmReference
Width143 cmReference
Height (cab)298 cmReference
Ground clearance49 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
