Tractor · 2001Unverified
Landini Legend 120
Landini Legend 120 — Legend Series · 117 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
117 hp
Weight
5501 kg
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Perkins 6.0L 6-cyl dieselReference
Fuel tank260.0 LReference
Engine (gross)87.5 kWReference
Engine (net)84.0 kWReference
Perkins 1006-60TReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
Power (net)84.0 kWReference
Power (gross)87.5 kWReference
Compression17.25:1Reference
Rated RPM2200Reference
Torque461.0 NmReference
Torque RPM1400Reference
Transmission
36-speed shuttleReference
72-speedReference
108-speedReference
TypeshuttleReference
Gears36 forward and reverseReference
TransmissionPower-sixReference
Gears72 forward and reverseReference
TransmissionDeltashiftReference
Gears108 forward and 36 reverseReference
PTO & Hydraulics
PTO (claimed)75.5 kWReference
Total flow62.1 lpmReference
Rear TypeIIIReference
Rear lift7001 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type1000 (1.75)Reference
Dimensions
Wheelbase279 cmReference
Weight5501 kgReference
Front tire380/70R28Reference
Rear tire480/70R38Reference
Ag front380/70R28Reference
Ag rear480/70R38Reference
Length512 cmReference
Width205 cmReference
Height (cab)278 cmReference
Ground clearance52 cmReference
Front tread180 to 221 cmReference
Rear tread159 to 209 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
