Tractor · 2001Unverified
Landini Rex 70
Landini Rex 70 — Model year 2001-20052006-20092010-2020 · 61 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
61 hp
Weight
5952 to 6173 pounds
Hover a source tag to verify
Overview
ManufacturerLandini (a part of Argo)Reference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post foldable mid-mount ROPS. Cab optional.Reference
Engine
Perkins 4.0L 4-cyl dieselReference
F Fuel tank53.0 LReference
GT Fuel tank62.1 LReference
Engine50.7 kWReference
Perkins 1004-40Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power50.7 kWReference
Compression17.25:1Reference
Rated RPM2200Reference
Torque263.1 NmReference
Torque RPM1300Reference
Starter volts12Reference
Transmission
12-speed shuttleReference
24-speed creeperReference
40-speedReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutch279.4mm dry discReference
TypecreeperReference
Gears24 forward and 12 reverseReference
TransmissionDeltashiftReference
Gears40 forward and 12 reverseReference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)45.5 kWReference
F Valves2Reference
GT Valves3Reference
Pump flow53.7 lpmReference
Total flow72.7 lpmReference
Total flow84.8 lpmReference
Steering flow18.9 lpmReference
Steering flow30.7 lpmReference
Rear TypeIIReference
Rear lift2600 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Dimensions
F Wheelbase201 cmReference
GT Wheelbase213 cmReference
Weight5952 to 6173 poundsReference
F Length344 cmReference
GT Length357 cmReference
V Length371 cmReference
F Width133 cmReference
GT Width149 cmReference
V Width123 cmReference
F Weight2699 kgReference
GT/F Weight2800 kgReference
Ground clearance38 cmReference
V Ground clearance24 cmReference
V Steering wheel130 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Landini Rex 70 Height
ROPS249 cmReference
Cab225 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
