The Lanz Bulldog D1306 is a compact tractor model rated at 13 hp, manufactured from 1955 to 1958. It features a 1-cylinder diesel liquid-cooled engine and a 6-speed gearbox, powering two-wheel drive. The listed weight of the tractor is 899 kg, and it is suited to tasks requiring up to 200 acres of land.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
899 kg
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded power
13 hp
Recorded weight
899 kg
Transmissions
6-speed gear
Production years
1955-1958
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLanzReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two-wheel driveReference
Open operator station.Reference
Engine
Lanz 0.5L 1-cyl dieselReference
Engine9.7 kWReference
LanzReference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement0.5 LReference
Bore/Stroke85 x 94 mmReference
Power9.7 kWReference
Rated RPM2800Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase167 cmReference
Weight899 kgReference
Front tire4.00-15Reference
Rear tire7-24Reference
Ag front4.00-15Reference
Ag rear7-24Reference
Ag rear8-24Reference
Length258 cmReference
Width156 cmReference
Height157 cmReference
Ground clearance43 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
