The Lanz Bulldog D2416 is a tractor model with a rated output of 24 hp — making it one of the more compact options in its class. This model was produced from 1955 to 1960. Under the hood is a 1-cylinder diesel liquid-cooled engine, driving through two-wheel drive with a 6-speed gearbox. It is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Catalogue coverage
Variants represented
2
Richest spec table
24 rows
Recorded power
24 hp
Transmissions
6-speed
Production years
1955-1960
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLanzReference
Standard-tread tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Lanz 2.6L 1-cyl dieselReference
Engine17.9 kWReference
LanzReference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke140 x 170 mmReference
Power17.9 kWReference
Rated RPM1050Reference
Transmission
6-speedReference
Gears6 forwardReference
Dimensions
Front tire5.50-16Reference
Rear tire8-36Reference
Ag front5.50-16Reference
Ag rear8-36Reference
Ag rear10-28Reference
D2416 Serial Number Location
Serial number plate on the right side of the tractor frame, above the front axle.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
