Lawn Tractor · 1988Unverified
Lawn Chief 700
Lawn Chief 700 — Garden tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Hover a source tag to verify
Overview
ManufacturerLawn ChiefReference
Garden tractorReference
Built in Harvard, Illinois, USAReference
Original price was $2,000 in 1990Reference
Two-wheel driveReference
Manual steeringReference
Open operator stationReference
Engine
18HP Briggs & Stratton 2-cyl gasolineReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft horizontally-opposedReference
Power (gross)13.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
Typebelt-driven gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Mid PTOindependentReference
Dimensions
Front tire16x6.50Reference
Rear tire23x9.50Reference
Lawn/turf front16x6.50Reference
Lawn/turf rear23x9.50Reference
Lawn Chief 700 attachments
45" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
45" mid-mount mower deckReference
SnowblowerReference
BladeReference
45" Mower deck
Typemid-mount Lawn ChiefReference
Type3-blade with manual liftReference
Cutting width114 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
