Industrial Tractor · 1945Unverified
Le Roi 105 Tractair
Le Roi 105 Tractair — Industrial tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1542 kg
Hover a source tag to verify
Overview
ManufacturerLe RoiReference
Industrial tractorReference
Built in Greenwich, Ohio, USAReference
Two-wheel driveReference
Open operator stationReference
Engine
Le Roi 3.7L 4-cyl gasolineReference
Fuel tank64.3 LReference
Engine26.1 kWReference
Le Roi D226Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.7 LReference
Bore/Stroke102 x 108 mmReference
Power26.1 kWReference
Air cleaneroil bathReference
Compression5.85:1Reference
Rated RPM1100Reference
Firing order1-2-4-3Reference
StarterelectricReference
Starter volts6Reference
Coolant capacity26.5 LReference
Point gap0.381 mmReference
Intake valve clearance0.305 mmReference
Exhaust valve clearance0.305 mmReference
Oil capacity6.6 LReference
Oil change120 hReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Dimensions
Weight1542 kgReference
Front tire6.00-16Reference
Rear tire10-24Reference
Industrial front6.00-16Reference
Industrial rear10-24Reference
Length304 cmReference
Width147 cmReference
Height134 cmReference
Rear tread121/132/142/152 cmReference
Le Roi 105 Tractair attachments
front-end loaderReference
105 Tractair Serial Numbers
Location:Serial number plate attached to the 105's engine.Reference
Electrical
Charging systemgeneratorReference
Battery volts6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
