Tractor · 1917Unverified
Leader 15-25
Leader 15-25 — Standard-tread tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
2268 kg
Hover a source tag to verify
Overview
ManufacturerLeader (a part of Dayton-Dick)Reference
Standard-tread tractorReference
Built in Quincy, Illinois, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Erd 4.9L 4-cyl keroseneReference
Drawbar (claimed)11.2 kWReference
Belt (claimed)18.6 kWReference
Plows3-4 (14-inch)Reference
ErdReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement4.9 LReference
Bore/Stroke102 x 152 mmReference
Fuel systemKingston carburetorReference
Rated RPM750Reference
Starter typehand crankReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and reverseReference
Dimensions
Weight2268 kgReference
Rear tire48x12Reference
Ag rear48x12 (steel)Reference
Length340 cmReference
Width152 cmReference
Height152 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
