Tractor · 1920Unverified
Leader GU 16-32
Leader GU 16-32 — Agricultural Crawler tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
3402 kg
Hover a source tag to verify
Overview
ManufacturerLeader (a part of Dayton-Dick)Reference
Agricultural Crawler tractorReference
Built in Quincy, Illinois, USAReference
Original price was $2,775 in 1921Reference
DrivecrawlerReference
Manual steeringReference
Open operator station.Reference
Engine
Climax 8.4L 4-cyl keroseneReference
Drawbar (claimed)11.9 kWReference
Belt (claimed)23.9 kWReference
Plows3-4 (14-inch)Reference
ClimaxReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement8.4 LReference
Bore/Stroke127 x 165 mmReference
Fuel systemStromberg carburetorReference
Rated RPM800Reference
Starter typehand crankReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight3402 kgReference
TracksReference
Length320 cmReference
Width147 cmReference
Height137 cmReference
Capacities
Diameter35 cmReference
Width17 cmReference
RPM800Reference
Speed883.92 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
