The Leader N 16-32 is a tractor with a rated power of 16 hp, categorising it as a lighter option within its class. It was manufactured between 1919 and 1924. The tractor features a 4-cylinder liquid-cooled engine and two-wheel drive with a 2-speed gearbox. Its operating weight is listed at 2268 kg, making it suitable for operations up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
2268 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
16 hp
Recorded weight
2268 kg
Transmissions
2-speed gear
Production years
1919-1924
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLeader (a part of Dayton-Dick)Reference
Standard-tread tractorReference
Built in Quincy, Illinois, USAReference
Original price was $1,985 in 1920Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Climax 8.4L 4-cyl keroseneReference
Drawbar (claimed)11.9 kWReference
Belt (claimed)23.9 kWReference
Plows3 (14-inch)Reference
ClimaxReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement8.4 LReference
Bore/Stroke127 x 165 mmReference
Rated RPM800Reference
Starter typehand crankReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight2268 kgReference
Rear tire54x12Reference
Ag rear54x12 (steel)Reference
Length340 cmReference
Width177 cmReference
Height182 cmReference
Capacities
Diameter35 cmReference
Width17 cmReference
RPM800Reference
Speed883.92 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
