Tractor · 1970Unverified
Leyland 154
Leyland 154 — Utility tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1054 kg
Hover a source tag to verify
Overview
ManufacturerLeylandReference
Utility tractorReference
Original price was $8,300 in 1984Reference
Two-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
BMC 1.5L 4-cyl dieselReference
BMC 1.6L 4-cyl gasolineReference
Fuel tank31.8 LReference
Engine20.9 kWReference
BMC 15TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke73 x 89 mmReference
Compression23:1Reference
Rated RPM2500Reference
BMC 16TReference
gasolineReference
Displacement1.6 LReference
Bore/Stroke76 x 89 mmReference
Power20.9 kWReference
Fuel systemZenith carburetorReference
Air cleaneroil bathReference
Compression7.2:1Reference
Torque96.3 NmReference
Torque RPM1250Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Oil capacity4.5 LReference
Transmission
9-speed constant meshReference
Typeconstant meshReference
Gears9 forward and 3 reverseReference
Clutch241mm dry discReference
Three gears, plus reverse, in three ranges.Reference
PTO & Hydraulics
PTO (claimed)17.9 kWReference
Typeopen centerReference
Pressure137.9 barReference
Pump flow14.4 lpmReference
Rear TypeIReference
Rear lift453 kgReference
Rear PTO Type540/1000Reference
Engine RPM540@2260Reference
Engine RPM1000@2440Reference
Dimensions
Wheelbase171 cmReference
Weight1054 kgReference
Front tire5.00-15Reference
Rear tire11.2/10-24Reference
Ag front5.00-15Reference
Ag rear11.2/10-24Reference
Ag front5.50-16Reference
Ag rear12.4/11-24Reference
Length260 cmReference
Width150 cmReference
Clearance (front axle)53 cmReference
Clearance (rear axle)48 cmReference
Front tread121 to 172 cmReference
Rear tread111 to 182 cmReference
Steering wheel128 cmReference
Electrical
Charging amps34Reference
Leyland 154 Height
Hood114 cmReference
Exhaust189 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
