Tractor · 1972Unverified
Leyland 270
Leyland 270 — Utility tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
5743 to 6305 pounds
Hover a source tag to verify
Overview
ManufacturerLeylandReference
Utility tractorReference
Two-wheel driveReference
Steeringpower assistReference
Mechanical dry disc brakesReference
Open operator station. Cab available.Reference
Engine
Leyland 3.8L 4-cyl dieselReference
Engine (gross)55.9 kWReference
Engine (net)52.9 kWReference
Leyland 4/98 NTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke98 x 125 mmReference
Power (net)52.9 kWReference
Power (gross)55.9 kWReference
Starter volts12Reference
Oil capacity9.0 LReference
Transmission
10-speed gearReference
TypegearReference
Gears10 forward and 2 reverseReference
Five gears (1-5) plus reverse (R) in two ranges (low/high).Reference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Hydraulic system56.0 LReference
Typeopen centerReference
Capacity56.0 LReference
Pressure180.0 barReference
Pump flow29.9 lpmReference
Rear TypeII/IReference
Rear lift1819 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@1813Reference
Capacities
Fuel68.1 LReference
Dimensions
Wheelbase202 cmReference
Weight5743 to 6305 poundsReference
Front tire7.50-16Reference
Rear tire18.4-30Reference
Ag front7.50-16Reference
Ag rear18.4-30Reference
Length340 cmReference
Width173 cmReference
Height (steering wheel)166 cmReference
Height (cab)242 cmReference
Shipping weight2605 kgReference
Shipping weight2859 kgReference
Ground clearance45 cmReference
270 Serial Number Location
Serial number plate on top of the tractor frame on the left sideReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
