Tractor · 1981Unverified
Leyland 802
Leyland 802 — Utility tractor · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
2971 kg
Hover a source tag to verify
Overview
ManufacturerLeylandReference
Utility tractorReference
Original price$20,500 (1984)Reference
Two-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with heat.Reference
Variants
8022WDReference
Engine
Leyland 3.8L 4-cyl dieselReference
Engine61.1 kWReference
Leyland 4/98 TTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke98 x 125 mmReference
Power61.1 kWReference
Compression16.8:1Reference
Rated RPM2200Reference
Starter volts12Reference
Transmission
9-speed synchromeshReference
TypesynchromeshReference
Gears9 forward and 3 reverseReference
Clutch305mm hydraulic dry discReference
PTO & Hydraulics
PTO (claimed)55.2 kWReference
Pressure179.3 barReference
Pump flow54.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2358 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Weight2971 kgReference
Front tire7.50x16Reference
Rear tire14.00x34Reference
Ag front7.50x16Reference
Ag rear14.00x34Reference
Electrical
Charging systemalternatorReference
Charging amps36Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
