Tractor · 1981Unverified
Leyland 804
Leyland 804 — Utility tractor · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
3039 kg
Hover a source tag to verify
Overview
ManufacturerLeylandReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Variants
8022WDReference
8044WDReference
Engine
Leyland 3.8L 4-cyl dieselReference
Engine61.1 kWReference
Leyland 4/98 TTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke98 x 125 mmReference
Power61.1 kWReference
Compression16.8:1Reference
Rated RPM2200Reference
Starter volts12Reference
Transmission
9-speedReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)55.2 kWReference
Rear TypeIIReference
Rear PTO Type540Reference
Dimensions
Weight3039 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
