The Limb LUXS 60 is a tractor with a rated power output of 49 hp, positioning it at the lighter end of its class. It was produced in 2005. The tractor features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 24-speed gearbox. Its listed operating weight is 3480 kg, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
3480 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
49 hp
Recorded weight
3480 kg
Transmissions
24-speed
Production years
2005-2005
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLimbReference
Built in Ptuj, SlovenijaReference
Four-wheel driveReference
cab with heat standard, air-conditioning optionalReference
Engine
Perkins 3.3L 3-cyl dieselReference
Fuel tank80.0 LReference
Engine43.3 kWReference
Perkins 1103C-33Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Power43.3 kWReference
Rated RPM2200Reference
Torque222.0 NmReference
Torque RPM1400Reference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)36.5 kWReference
Valves2Reference
Valves3 optionalReference
Total flow50.0 lpmReference
Rear TypeIIReference
Rear PTO Type540/540EReference
Front PTOoptionalReference
Front PTO Type2000Reference
Dimensions
Wheelbase230 cmReference
Weight3480 kgReference
Front tire320/70R24Reference
Rear tire18.4R30Reference
Ag front320/70R24Reference
Ag rear18.4R30Reference
Length384 cmReference
Width194 cmReference
Height243 cmReference
Ground clearance42 cmReference
Electrical
Charging amps65Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
