Tractor · 2005Unverified
Limb LUXS 80
Limb LUXS 80 · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Weight
3979 kg
Hover a source tag to verify
Overview
ManufacturerLimbReference
Built in Ptuj, SlovenijaReference
Four-wheel driveReference
cab with heat standard, air-conditioning optionalReference
Variants
Foresterwith Igland winch and forestry equipmentReference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank84.0 LReference
Engine61.1 kWReference
Perkins 1104C-44Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Power61.1 kWReference
Rated RPM2200Reference
Torque294.0 NmReference
Torque RPM1400Reference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)52.9 kWReference
Valves2Reference
Valves3 optionalReference
Total flow60.0 lpmReference
Rear TypeIIReference
Rear PTO Type540/540EReference
Front PTOoptionalReference
Front PTO Type2000Reference
Dimensions
Wheelbase242 cmReference
Weight3979 kgReference
Front tire320/70R24Reference
Rear tire18.4R30Reference
Ag front320/70R24Reference
Ag rear18.4R30Reference
Length395 cmReference
Width205 cmReference
Height257 cmReference
Ground clearance42 cmReference
Electrical
Charging amps65Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
