Tractor · 1975Unverified
Long 1100
Long 1100 — Row-Crop tractor · 92 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
92 hp
Weight
3628 kg
Hover a source tag to verify
Overview
DistributorLongReference
ManufacturerZetorReference
Row-Crop tractorReference
Two-wheel driveReference
Steeringhydraulic powerReference
Differential hydraulic wet disc brakesReference
ROPS. Cab optional.Reference
Engine
Zetor 4.7L 4-cyl dieselReference
Engine78.3 kWReference
ZetorReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.7 LReference
Bore/Stroke110 x 120 mmReference
Power78.3 kWReference
Compression17:1Reference
Rated RPM2200Reference
Torque379.7 NmReference
Oil capacity9.9 LReference
Coolant capacity18.0 LReference
Transmission
16-speed partial power shiftReference
Typepartial power shiftReference
Gears16 forward and 8 reverseReference
Eight forward, and four reverse, gears with a under-drive power shift.Reference
PTO & Hydraulics
PTO (claimed)68.6 kWReference
Rear TypeIIReference
Rear lift2404 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Capacities
Fuel140.0 LReference
Steering7.1 LReference
Dimensions
Wheelbase234 cmReference
Weight3628 kgReference
Front tire9.5Lx15Reference
Rear tire16.9x34Reference
Ag front9.5Lx15Reference
Ag rear16.9x34Reference
Ag front23.1x26Reference
Ag rear18.4x34Reference
Ag rear11Lx15Reference
Length393 cmReference
Width193 cmReference
Shipping weight3628 kgReference
Ground clearance53 cmReference
Front tread162 to 223 cmReference
Rear tread149 to 172 cmReference
Rear tread162 to 223 cmReference
Speeds
With 16.9x34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
