The Long 470 is a tractor with a rated power output of 41 hp, positioning it at the lower power end of its class. It was produced from 1999 to 2001 and features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and an 8-speed gearbox. This model is suitable for operations covering areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
41 hp
Transmissions
8-speed shuttle
Production years
1999-2001
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLongReference
Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 2.5L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine35.0 kWReference
MitsubishiReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke88 x 103 mmReference
Power35.0 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed shuttleReference
TypeshuttleReference
Gears8 forward and reverseReference
Clutch275mm dry discReference
PTO & Hydraulics
PTO (claimed)30.6 kWReference
Typeopen centerReference
Pump flow34.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1349 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase184 cmReference
Front tire7.5x20Reference
Rear tire13.6x28Reference
Standard tires (ag)Front: 7.5x20. Rear: 13.6x28Reference
Length347 cmReference
Width165 cmReference
Height (ROPS)238 cmReference
Ground clearance35 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery CCA600Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
