Tractor · 2002Unverified
Long 480
Long 480 — Utility tractor · 48 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Hover a source tag to verify
Overview
DistributorLongReference
ManufacturerUTBReference
Utility tractorReference
Two- or four-wheel driveReference
Mechanical band brakesReference
Two-post fixed ROPS.Reference
Variants
4802WDReference
480DTC4WDReference
Engine
UTB 2.8L 3-cyl dieselReference
Fuel tank62.1 LReference
Engine (gross)35.8 kWReference
UTBReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Power (gross)35.8 kWReference
Rated RPM2400Reference
Oil capacity6.0 LReference
Coolant capacity13.2 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Oil capacity20.0 LReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
Valves2Reference
Pump flow34.1 lpmReference
Rear TypeII/IReference
Rear lift1199 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
2WD Wheelbase210 cmReference
4WD Wheelbase213 cmReference
Front tire6.00-16Reference
2WD Rear tire14.9-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 14.9-28Reference
4WD Standard tires (ag)Front: 8.3-24. Rear: 14.9-28Reference
Long 480 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps36Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
