Tractor · 1975Unverified
Long 560
Long 560 — Utility tractor · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Max power
34.8 kW
Weight
2072 kg
Hover a source tag to verify
Overview
DistributorLongReference
ManufacturerUTB/UniversalReference
Utility tractorReference
Built in Brasov, RomaniaReference
Two- or four-wheel driveReference
Differential lockpedal with auto-disengagementReference
SteeringmanualReference
Steeringpower optionalReference
Independent contracting band brakesReference
Open operator station.Reference
Variants
560DT4WDReference
Engine
UTB/Universal 3.1L 4-cyl dieselReference
Engine44.7 kWReference
Drawbar (tested)34.8 kWReference
UTB/Universal D-121Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Bore/Stroke95 x 110 mmReference
Power44.7 kWReference
Compression17:1Reference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity10.5 LReference
Coolant capacity13.9 LReference
Power at rated engine speed40.0 kWReference
Max power34.8 kWReference
Transmission
8-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 2 reverseReference
Oil capacity17.0 LReference
Shifts between gears 3-4 and 7-8 are synchronized.Reference
PTO & Hydraulics
PTO (tested)40.0 kWReference
Hydraulic system17.0 LReference
Capacity17.0 LReference
Pressure147.1 barReference
Total flow21.8 lpmReference
Rear TypeIReference
Rear lift1206 kgReference
Rear PTO Type540Reference
Power at rated PTO speed35.5 kWReference
Capacities
Fuel53.9 LReference
Dimensions
Wheelbase206 cmReference
Weight2072 kgReference
Front tire7.50-16Reference
Rear tire14.9-28Reference
Ag front7.50-16Reference
Ag rear14.9-28Reference
Ag rear16.9-28Reference
Ag rear18.4-28Reference
Length345 cmReference
Height (hood)137 cmReference
Operating weight2072 kgReference
Ballasted weight4132 kgReference
Ground clearance46 cmReference
Front tread132 to 200 cmReference
Rear tread120 to 189 cmReference
Test results
Diesel 8-speed 2WDSeptember 21 - October 2, 1972Link: Nebraska Tractor Test 1109 fileReference
PTO performanceReference
Fuel use13.6 l/hourReference
Fuel use12.1 l/hourReference
Drawbar performanceReference
Gear 5 used for power test.Reference
Max pull3149 kgReference
Gear 2 used for pull test.Reference
Speeds
With 14.9x28 rear tiresReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
