Tractor · Unverified
LS G33
LS G33 — G SeriesCompact Utility tractor · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1183 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
ROPS.Reference
Engine
LS 1.9L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine24.6 kWReference
LS L3BLReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke88 x 105 mmReference
EmissionsInterim Tier 4Reference
Power24.6 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronized shuttleReference
hydrostaticReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)21.2 kWReference
Hydro PTO (claimed)19.8 kWReference
Rear valves1Reference
Pump flow26.9 lpmReference
Total flow42.4 lpmReference
Steering flow15.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift820 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase167 cmReference
Weight1183 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Length298 cmReference
Width120 cmReference
Height (ROPS)229 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
