LS i38
LS i38 — I SeriesCompact Utility tractor · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1404 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
ROPS.Reference
Engine
LS 2.0L 3-cyl dieselReference
Fuel tank32.2 LReference
Engine28.3 kWReference
LS L3ALReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke90 x 105 mmReference
EmissionsInterim Tier 4Reference
Power28.3 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronized shuttleReference
hydrostaticReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)24.0 kWReference
Hydro PTO (claimed)22.6 kWReference
Rear valves1 or 2Reference
Front valves2Reference
Pump flow26.9 lpmReference
Total flow40.1 lpmReference
Steering flow13.2 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift820 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase166 cmReference
Weight1404 kgReference
Front tire7-16Reference
Rear tire12.4-24Reference
Ag front7-16Reference
Ag rear12.4-24Reference
Length298 cmReference
Width137 cmReference
Height (ROPS)235 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
