Tractor · 2009Unverified
LS J2020H
LS J2020H — J Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
709 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Mitsibishi 1.1L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine (gross)17.2 kWReference
Mitsibishi S3LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 79 mmReference
Power (gross)17.2 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.0 kWReference
Pump flow22.3 lpmReference
Total flow32.6 lpmReference
Steering flow10.2 lpmReference
Rear TypeIReference
Rear lift650 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase149 cmReference
Weight709 kgReference
Weight204 kgReference
Lawn/turf front23x8.5-12Reference
Lawn/turf rear33x12-16.5Reference
Industrial front23x8.5-12Reference
Industrial rear33x12-16.5Reference
Length261 cmReference
Width114 cmReference
Height (ROPS)215 cmReference
LS J2020H attachments
60" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount LS LM3560Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width187 cmReference
Cut height2 to 10 cmReference
LS LB1103 Backhoe
Backhoe typeLS LB1103 BackhoeReference
Digging depth195 cmReference
Reach from pivot290 cmReference
Loading height157 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force938 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
